Available in full-height and half-height variants, the Cosmopolitan duct panel system utilises postformed edges for a softer more sophisticated look and feel. Manufactured from High-Pressure laminates Cosmopolitan duct panels in high traffic, moderate impact dry situations such as corporate offices, hotels, retail establishments and conference facilities.
Available as either pre-plumbed units complete with sanitaryware or as a simple panel system to be configured by others, Cosmopolitan duct panels can be made in a wide variety of widths and panel splits to suit your project.
Applications
Being suitable for any high traffic, moderate impact, dry environment means that Cosmopolitan ducts work best in office, hotel, conference and other situations where there are lots of people and lots of use but that use is reasonable and the system is only subjected to normal wear and tear. The wide range of available colours and woodgrains and the use of vertical postformed edges means the Cosmopolitan system can be designed in a way that can contribute to the sophisticated or luxurious ‘feel’ the designer is looking for.
Manufacture
Cosmopolitan duct panels are manufactured from High-Pressure laminate on an 18mm MR core. Panels can be manufactured in almost any normal width and height and are normally supplied so they butt together on horizontal joints with a matching or contrasting shadowgap detail showing on the vertical section between panels sets. The panels are supplied with concealed fixing clips which allow for access to services behind the duct sets. The associated shadowgap framework is manufactured from High-Pressure laminate on a 36mm MR core to provide ultimate flexibility for system widths and splits.
To complete your project Inscape can also provide:
- Complete range of complementary WC Cubicle Systems and Vanity Units
- Shower Cubicles, Lockers and Bench Seating also available
- Full On-Site installation service
- Off-Site Modular Manufacturing
- Loose sanitaryware
- Stainless Steel Washroom Accessories (soap dispensers, paper towel holders, etc)
- Fitted Furniture & Equipment (cabinets, worktops, tray units, etc)
- CAD drawings provided as standard
- 3D visualisations available to support your project
Dimensions
Manufactured in a variety of panel widths to cover any wall length, the Cosmopolitan duct system can accommodate all variations of individual panel splits to reach the ceiling height of your project. Panel splits for WC’s, Urinals, Wash Hand Basins, etc., will vary from project to project and a range of typical splits for any given panel type are available to download from our technical section.
Information
| |
|
|
|
| Manufacturer |
Inscape Interiors Limited, Lower Healey Business Park, Froom Street, Chorley. PR6 9AR |
|
|
| Core Material |
18mm MR MDF (Other core materials available on request) |
|
|
| Colour Ways |
Face side with high pressure laminate from the Abet, Formica or Polyrey WC cubicle ranges. Balancing laminate to reverse |
|
|
| Edge Details |
Postformed vertical edge with 2mm ABS lipping to horizontal edges |
|
|
| Panel fixing |
Concealed anti-tamper clips |
|
|
| Sub-frame |
30mm Decorative Faced MR MDF |
|
|
| Hinged (Option) |
Panels can be hinged for service access |
|
|
| Pre-Plumbing (Option) |
Sanitaryware can be pre-mounted with copper tails to rear |
|
|
“Panels:
– Type: Manufacturers standard.
– Core material: Moisture resistant MDF
Thickness: 18mm
– Facings: Decorative High Pressure Laminate (HPL) face and balancer to reverse.
Colour / Finish: TBC from Inscapes offered colour brochure.
– Edge Treatment: Postformed verticle edges and matching PVC Square Edge on the horizontal.
“Fasteners:
– Type: Concealed Heavy Load Accessible KEKU Suspension Clipping System
“Frame:
– Core material: Moisture resistant MDF
Thickness: 25mm.
– Facings: Decorative high pressure laminate (HPL) face and balancer to reverse.
Colour / Finish: TBC from Inscapes offered colour brochure
“Options:
– Box Unit frames are free standing and manufactured from 25mm MR MDF with decorative laminate face and balancer to rear.
– Cosmopolitan Speedfix; 20mm Panels pre-mounted to timber ladder frame installed on a 27mm decorative frame.
– Cosmopolitan Hinged; 20mm HPL Panels pre-mounted to timber ladder frame with access panels (800mm high max) hinged and installed on a 27mm decorative frame.
– Pre-Plumbed; Sanitary ware, where appropriate, is pre-mounted to panels ready for final connection on site. Please contact us for more details.
Cosmopolitan IPS Technical Sheet
