Combining aesthetics and functionality, the Cosmopolitan range is a versatile cubicle system that lends a sturdy yet stylish character to high traffic, dry areas such as hotels, offices and leisure facilities.
Suiting both new-build and refurbishment projects the Cosmopolitan range is readily available and designed to work within your budget and lead-time constraints.
Perfectly suited for clients who require design flexibility, aesthetics and functionality. Ideal for high traffic, dry areas that require superior colour-ways and design features, the Cosmopolitan is perfectly at home in prestigious new or existing developments such as hotels, offices and leisure facilities.
The partitions and doors are manufactured from 18mm moisture resistant core material faced both sides with high-pressure laminates. The pilasters are manufactured from 36mm moisture resistant core and are post-formed to the front vertical edges avoiding the sharp edges of other designs, leaving a more pleasing and gentle look to the system. Post-formed headrail inserts (provided as standard with the Cosmopolitan), complete the quality look and feel of this product.
These dimensions are typical and for guidance only as our cubicle systems are designed to suit the clients specific requirements.
| Thickness | Height | Width | |
|---|---|---|---|
| Partitions | 20mm | 1800mm | 1500mm |
| Doors | 20mm | 1800mm | 600-900mm |
| Pilasters | 38mm | 1800mm | 80mm (min.) |
| Headrail inserts (if required) | 20mm | 35mm | to suit door gap |
All dimensions are nominal as exact dimensions may vary slightly to accommodate the bespoke nature of the project. Typical cubicle height is 1950mm including the adjustable leg. Typical ground clearance is 150mm (adjustable from 125-175mm).
| Cosmopolitan | |
|---|---|
| Manufacturer | Inscape Interiors Limited, Lower Healey Business Park, Froom Street, Chorley. PR6 9AR |
| Core Material | 18mm MR Chipboard (Other core materials available on request). |
| Colour Ways | Faced both sides with high pressure laminate from the Abet, Formica or Polyrey WC cubicle ranges. |
| Edge Details | 2mm ABS lipping to all divisions and doors |
| Floor Supports | Adjustable aluminium circular section support pedestals |
| Accessories | Indicator Bolt, Hinges, Headrail, Fixing Cleats, Coat Hook and Toilet Roll Holder |
” Frame:
– Type: Manufacturer’s standard.
– Height: 1950mm – 2700mm
– Material/ finish:
Head rail: Aluminium Angle in Satin Anodised Aluminium with a Decorative High Pressure Laminate post-formed infill piece.
Pedestal leg: Satin Anodised Aluminium Leg, fixed through cubicle division.
” Dividing Panels:
– Height: Between 1950mm – 2700mm
– Floor clearance: Between 50mm and 150mm
– Core material: Moisture resistant MDF
Thickness: 18mm
– Facings: Decorative High Pressure Laminate (HPL) face and balancer to reverse.
Colour/ Pattern/ Species: TBC from Inscape offered colour brochure.
– Edge treatment: Matching PVC Square Edged.
” Pilasters:
– Height: Between 1950mm – 2700mm.
– Core material: Moisture resistant MDF.
Thickness: 36mm
– Facings: Decorative High Pressure Laminate (HPL) face and balancer to reverse.
Colour/ Pattern/ Species: TBC from Inscape offered colour brochure.
– Edge treatment: Post-formed vertical edges with matching laminate on the horizontal top and bottom.
” Doors:
– Height: Between 1950mm – 2700mm.
– Core material: Moisture resistant MDF..
Thickness: 18mm
– Facings: Decorative High Pressure Laminate (HPL) face and balancer to reverse.
Colour/ Pattern/ Species: TBC from Inscape offered colour brochure.
– Edge treatment: Matching PVC Square Edged.
“ Ironmongery:
Aluminium rise & fall pivot hinge, coat hook, DDA compliant indicator bolt
with high visibility red and white circular face plate, integral door buffer.
Colour: Satin Anodised Aluminium
Note: Outward opening doors supplied with outward opening keep.
” Accessories:
Coat hook
“ Optional Extras:
SAA Fittings can be powder colour coated at an additional cost.
D shaped pull handle available at additional cost.
