Working in close harmony with the designer, Volcae represents a unique system which is equally at home in the most prestigious of buildings as it is in office and leisure facilities.
With both HPL (for dry areas), and Extremus (solid laminate for wet areas) available Volcae is the perfect blend of design, cost and rigour.
Applications
From prestigious corporate offices to hardworking leisure facilities and everything in between. Volcae is available in high pressure laminate panels for dry, moderate use applications, and in a solid laminate Extremus version for when the going gets wet or tough or both!!
Manufacture
Partitions and doors may be manufactured from either 20mm high-pressure laminate panels using a moisture resistant core, or from 12mm solid grade laminate dependant upon likely wear and tear or whether ‘wet area’ use is required.
The fascias comprise of a strong curved aluminium profile to provide a striking visual impact.
To complete your project Inscape can also provide:
- Complete range of Duct Panel Systems and Vanity Units
- Shower Cubicles, Lockers and Bench Seating also available
- Full On-Site installation service
- Off-Site Modular Manufacturing
- Loose sanitaryware
- Stainless Steel Washroom Accessories (soap dispensers, paper towel holders, etc)
- Fitted Furniture & Equipment (cabinets, worktops, tray units, etc)
- CAD drawings provided as standard
- 3D visualisations available to support your project
Volcae Extremus
” Frame:
– Type: Manufacturer’s standard.
– Height: 2000mm – 2600mm (Dependent on chosen range of laminate)
– Material/ finish:
Head rail: D shaped Aluminium Headrail with capped end.
Pedestal leg: Satin Anodised Aluminium Leg.
” Panels/Dividers:
– Height: 2000mm – 2600mm (Dependent on chosen range of laminate)
– Floor clearance: 50mm-150mm
– Core material: Solid grade laminate
– Thickness: 12/13mm depending on laminate brand.
– Facings: Coloured compact faced both sides.
– Colour/ Pattern/ Species: TBC from Inscape offered colour brochure.
– Edge treatment: Crescent Edge Polished Profile.
” Pilasters:
– Elliptical Aluminium
” Doors:
– Height: (overall): Up to 2600mm (Dependent on chosen range of laminate)
– Core material: Solid grade laminate.
– Thickness: 12/13mm depending on laminate brand.
– Facings: Coloured compact faced both sides.
– Colour/ Pattern/ Species:TBC from Inscape offered colour brochure.
– Edge treatment: Crescent Edge Polished Profile.
“ Ironmongery:
-SAA Rise & Fall hinges, Coat Hook, DDA compliant Indicator Bolt with
high visibility red and white circular face plate, integral door buffer and
emergency release facility, U-Channel Fixing, adjustable Pedestal Support Legs,
SAA Headrail Bracing channel
Colour: Satin Anodised Aluminium
Note: Outward opening doors supplied with outward opening keep.
Volcae Industria Plus
” Frame:
– Type: Manufacturer’s standard.
– Height: 2000mm – 2600mm (Dependent on chosen range of laminate)
– Material/ finish:
Head rail: D shaped Aluminium Headrail with capped end.
Pedestal leg: Satin Anodised Aluminium Leg.
” Panels/Dividers:
– Height: 2000mm – 2600mm (Dependent on chosen range of laminate)
– Floor clearance: 50mm-150mm
– Core material: Moisture resistant MDF
– Thickness: 18mm- Facings: Decorative High Pressure Laminate (HPL) face and balancer to reverse.
– Colour/ Pattern/ Species: TBC from Inscape offered colour brochure.
– Edge treatment: Matching PVC Square Edged.
” Pilasters:
– Elliptical Aluminium
” Doors:
– Height: (overall): Up to 2600mm (Dependent on chosen range of laminate)
– Core material: Moisture resistant MDF
– Thickness: 18mm- Facings: Decorative High Pressure Laminate (HPL) face and balancer to reverse.
– Colour/ Pattern/ Species: TBC from Inscape offered colour brochure.
– Edge treatment: Matching PVC Square Edged.
“ Ironmongery:
-SAA Rise & Fall hinges, Coat Hook, DDA compliant Indicator Bolt with
high visibility red and white circular face plate, integral door buffer and
emergency release facility, U-Channel Fixing, adjustable Pedestal Support Legs,
SAA Headrail Bracing channel
Colour: Satin Anodised Aluminium
Note: Outward opening doors supplied with outward opening keep.
